Torayca® Carbon Fibers
Product Selector Chart
Product Selector Chart
Select a carbon fiber from our Torayca® range of products
Find the ideal Torayca® carbon fiber for your application – rigidity, resistance or lightness.
Simply click on each of our products in the Product Selector Chart below:
Torayca® Carbon Fibers- Product Selector Chart
Standard Modulus
T300 / FT300
| Tensile Strength (MPa) |
Tensile Modulus (Gpa) |
Elongation (%) |
Density g/cm3 |
| 3530 | 230 | 1,5 | 1,76 |
Fiber Family
| Fiber Grade | T300 1K 50A | T300B 1K 50B | FT300 3K 40A | FT300B 3K 40B | FT300 6K 50A | FT300 6K 50B | FT300 6K 40D |
| Yield (g/1000m) | 66 | 198 | 396 | ||||
| Sizing Content (% wt) | 1 | 1 | 1 | 1 | 1 | 1 | 0,7 |
| Fiber Type | Twisted | Untwisted | Twisted | Untwisted | Twisted | Untwisted | Untwisted |
| SurfaceTreatment (fiber / matrix adhesion) | Standard | ||||||
| Typical Matrix Compatibility Recommendation | Epoxy, Polyester, Vinylester, Phenolic, BMI | Epoxy, Phenolic, BMI | Epoxy, Polyester, Vinylester, Phenolic, BMI | Epoxy, Phenolic, BMI | |||
| Typical Process Recommendation | Stitching; Braiding | Weaving | Braiding; Filament Winding | Weaving | Braiding; Filament Winding | Braiding; Filament Winding | Weaving, Prepreg |
| Supply Source |  |
 |
|||||
| Market | Space, Automotive Seat Heating Systems | Visual Applications Fabric | Automotive Seat Heating Systems, Industrial Applications | Visual Applications Fabric, IT Casing, Industrial Applications | Industrial Applications | ||
T300J
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 4210 | 230 | 1,8 | 1,78 |
Fiber Family
| Fiber Grade | T300J 3K 40A | T300JB 3K 40B | T300J 6K 40A | T300J 6K 40B |
| Yield g/1000m | 198 | 396 | ||
| Sizing Content (% wt) | 1 | 1 | 1 | 1 |
| Fiber Type | Twisted | Untwisted | Twisted | Untwisted |
| SurfaceTreatment (fiber / matrix adhesion) |
Standard | |||
| Typical Matrix Compatibility Recommendation | Epoxy, Phenolic, BMI | |||
| Typical Process Recommendation | Braiding; Filament Winding |
Weaving; Prepreg | Braiding; Filament Winding |
Weaving; Prepreg |
| Supply Source | |
|||
| Market | Aerospace | |||
T620SC
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 4300 | 235 | 1,8 | 1,77 |
Fiber Family
| Fiber Grade | T620SC 24K 50C | T620SC 24K 60E |
| Yield g/1000m | 1850 | |
| Sizing Content (% wt) | 1 | 0,3 |
| Fiber Type | Never twisted | |
| SurfaceTreatment (fiber / matrix adhesion) |
Standard | |
| Typical Matrix Compatibility Recommendation | Epoxy, Polyester, Vinylester, Phenolic, BMI | Epoxy, Polyester |
| Typical Process Recommendation | Weaving, RTM, prepreg | RTM, prepreg |
| Supply Source | |
|
| Market | Automotive Structural Applications | |
T700GC
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 4900 | 240 | 2,0 | 1,78 |
Fiber Family
| Fiber Grade | T700GC 12K 31E |
| Yield g/1000m | 800 |
| Sizing Content (% wt) | 0,5 |
| Fiber Type | Never twisted |
| SurfaceTreatment (fiber / matrix adhesion) |
Enhanced |
| Typical Matrix Compatibility Recommendation | Epoxy |
| Typical Process Recommendation | Prepreg |
| Supply Source |  |
| Market | Aeronautic Primary Structures, Automotive |
T700SC
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 4900 | 230 | 2,1 | 1,8 |
Fiber Family
| Fiber Grade | T700SC 12K 50C | T700SC 12K 60E | T700SC 12K F0E | T700SC 12K 20C | T700SC 24K 50C | T700SC 24K 60E | T700SC 24K F0E |
| Yield g/1000m | 800 | 1650 | |||||
| Sizing Content (% wt) | 1 | 0,3 | 0,7 | 1 | 1 | 0,3 | 0,7 |
| Fiber Type | Never twisted | ||||||
| SurfaceTreatment (fiber / matrix adhesion) |
Standard | ||||||
| Typical Matrix Compatibility Recommendation | Epoxy, Polyester, Vinylester, Phenolic, BMI | Epoxy, Polyester, Polyamide | Epoxy, Polyester, Vinylester | Epoxy | Epoxy, Polyester, Vinylester, Phenolic, BMI | Epoxy, Polyester | Epoxy, Polyester, Vinylester |
| Typical Process Recommendation | Weaving, Filament Winding, Braiding, Pultrusion | Infusion, RTM, Prepreg, Pultrusion, TP UD tape (hot-melt) | Infusion, RTM | Weaving and spreading processes | Filament winding, Weaving, Braiding | Infusion, RTM, Prepreg | Infusion, RTM |
| Supply Source |  |
|
|
|
|
|
|
| Market | Pressure Vessels (SCBA), Sporting Goods, Automotive | Automotive Body Panels, Tooling | Marine: Ferries and Yachts, Wind Energy | Lightweight Plies, Visual Applications Bulk Plies Fabrics, Tooling | Pressure Vessels (CNG) | Automotive | Marine: Ferries and Yachts, Wind Energy |
T720SC
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 5880 | 265 | 2,2 | 1,8 |
Fiber Family
| Fiber Grade | T720SC 36K 50C |
| Yield g/1000m | 1650 |
| Sizing Content (% wt) | 1 |
| Fiber Type | Never twisted |
| SurfaceTreatment (fiber / matrix adhesion) |
Standard |
| Typical Matrix Compatibility Recommendation | Epoxy, Polyester, Vinylester, Phenolic, BMI |
| Typical Process Recommendation | Filament winding, Weaving, Prepreg, Braiding |
| Supply Source | |
| Market | Pressure Vessels (CNG, SCBA) |
| Granted patent rights | Patent N°: EP3467165B1, 602017019957.5 (Germany), 3467165 (France)
Assignee: Toray Industries, Inc. |
Intermediate Modulus
M30SC
| Résistance en traction (MPa) |
Module de traction (GPa) |
Elongation (%) |
Densité (g/cm3) |
| 5490 | 294 | 1,9 | 1,73 |
Gammes de fibre de carbone
| Gamme de fibre de carbone |
M30SC 12K 50C | M30SC 18K 50C |
| Poids au mètre (g) | 522 | 760 |
| Teneur en ensimage (%) | 1 | |
| Type de fibre de carbone | Plate | |
| Traitement de surface (adhérence fibre / matrice) |
Standard | |
| Recommandation de matrices types |
Epoxy, Polyester, Vinylester, Phénolique, BMI | |
| Recommandation de procédés types | Tissage Pré-imprégnation Tressage Enroulement filamentaire |
|
| Approvisionnement | |
|
| Principales applications | Sport Aéronautique et Spatial |
|
T800H
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 5490 | 294 | 1,9 | 1,81 |
Fiber Family
| Fiber Grade | T800H 6K 40A | T800HB 6K 40B | T800H 12K 40A | T800HB 12K 40B |
| Yield g/1000m | 223 | 445 | ||
| Sizing Content (% wt) | 1 | 1 | 1 | 1 |
| Fiber Type | Twisted | Untwisted | Twisted | Untwisted |
| SurfaceTreatment (fiber / matrix adhesion) |
Standard | |||
| Typical Matrix Compatibility Recommendation | Epoxy, Phenolic, BMI | |||
| Typical Process Recommendation | Braiding, Filament Winding | Weaving, Prepreg | Braiding, Filament Winding | Weaving, Prepreg |
| Supply Source | |
|||
| Market | Nuclear Enrichment | F1 | Nuclear Enrichment, Space Launchers |
F1, Marine, Racing Sailboats |
T800SC / T800GC
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 5880 | 294 | 2 | 1,8 |
Fiber Family
| Fiber Grade | T800SC 24K 10E | T800GC 24K 71E |
| Yield g/1000m | 1030 | |
| Sizing Content (% wt) | 0,5 | 0,6 |
| Fiber Type | Never twisted | |
| SurfaceTreatment (fiber / matrix adhesion) |
Standard | Enhanced |
| Typical Matrix Compatibility Recommendation | Epoxy | |
| Typical Process Recommendation | Prepreg, Weaving, Filament winding, compound | Prepreg |
| Supply Source | |
|
| Market | Aeronautic Primary Structures, Marine, Cable Core, Civil Engineering, Sports Cars, Industrial Rollers | Aeronautic Primary Structures |
T1000G
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 6370 | 294 | 2,2 | 1,8 |
Fiber Family
| Fiber Grade | T1000GB 12K 40D |
| Yield g/1000m | 485 |
| Sizing Content (% wt) | 0,7 |
| Fiber Type | Untwisted |
| SurfaceTreatment (fiber / matrix adhesion) |
Standard |
| Typical Matrix Compatibility Recommendation | Epoxy, Phenolic, BMI |
| Typical Process Recommendation | Weaving, prepreg, filament winding, and others |
| Supply Source | |
| Market | Aerospace, F1, Commercial Cars |
T1100GC / T1100SC
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 7000 | 324 | 2 | 1,79 |
Fiber Family
| Fiber Grade | T1100GC 12K 71E | T1100GC 24K 71E | T1100SC 12K 50C | T1100SC 24K 50C |
| Yield g/1000m | 505 | 1010 | 505 | 1010 |
| Sizing Content (% wt) | 0,6 | 1 | ||
| Fiber Type | Never twisted | |||
| SurfaceTreatment (fiber / matrix adhesion) |
Enhanced | Standard | ||
| Typical Matrix Compatibility Recommendation | Epoxy | Epoxy, Polyester, Vinylester, Phenolic, BMI | ||
| Typical Process Recommendation | Prepreg, compound | Filament winding, braiding | ||
| Supply Source | |
|||
| Market | Aerospace Structures, F1 | Pressure Vessels (Aerospace) | ||
T1200
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 8000 | 315 | 2,5 | 1,82 |
High Modulus
M40
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 2740 | 392 | 0,7 | 1,81 |
Fiber Family
| Fiber Grade | M40B 12K 50B |
| Yield g/1000m | 728 |
| Sizing Content (% wt) | 1 |
| Fiber Type | Untwisted |
| SurfaceTreatment (fiber / matrix adhesion) |
Standard |
| Typical Matrix Compatibility Recommendation | Epoxy, Polyester, Vinylester, Phenolic, BMI |
| Typical Process Recommendation | Weaving; Prepreg, Braiding; Filament Winding |
| Supply Source | |
| Market | Robotics Arms, Civil Engineering |
M40J
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 4400 | 377 | 1,2 | 1,77 |
Fiber Family
| Fiber Grade | M40JB 6K 50B | M40JB 12K 50B |
| Yield g/1000m | 225 | 450 |
| Sizing Content (% wt) | 1 | 1 |
| Fiber Type | Untwisted | |
| SurfaceTreatment (fiber / matrix adhesion) |
Standard | |
| Typical Matrix Compatibility Recommendation | Epoxy, Polyester, Vinylester, Phenolic, BMI | |
| Typical Process Recommendation | Weaving; Prepreg, Braiding; Filament Winding | |
| Supply Source | |
|
| Market | Marine MASTS, F1, Space, Sports and Leisure | |
M40X
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 5500 | 377 | 1,5 | 1,79 |
M46J
Fiber Family
| Fiber Grade | M46JB 6K 50B | M46JB 12K 50B |
| Tensile Strength MPa | 4200 | 4020 |
| Tensile Modulus GPa | 436 | |
| Elongation (%) | 1 | 0,9 |
| Density g/cm3 | 1,84 | |
| Yield g/1000m | 223 | 445 |
| Sizing Content (% wt) | 1 | 1 |
| Fiber Type | Untwisted | |
| SurfaceTreatment (fiber / matrix adhesion) |
Standard | |
| Typical Matrix Compatibility Recommendation | Epoxy, Polyester, Vinylester, Phenolic, BMI | |
| Typical Process Recommendation | Weaving; Prepreg, Braiding; Filament Winding | |
| Supply Source | |
|
| Market | Marine MASTS, F1, Space, Medical | |
M46X
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 5000 | 437 | 1,1 | 1,84 |
M55J
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 4020 | 540 | 0,8 | 1,91 |
Fiber Family
| Fiber Grade | M55J 6K 50A | M55JB 6K 50B |
| Yield g/1000m | 218 | |
| Sizing Content (% wt) | 1 | 1 |
| Fiber Type | Twisted | Untwisted |
| SurfaceTreatment (fiber / matrix adhesion) |
Standard | |
| Typical Matrix Compatibility Recommendation | Epoxy, Polyester, Vinylester, Phenolic, BMI | |
| Typical Process Recommendation | Braiding; Filament Winding | Weaving; Prepreg |
| Supply Source | |
|
| Market | Launchers, Satellites, Commercial Aeroplanes, F1, Sports and Leisure | |
M60J
| Tensile Strength MPa |
Tensile Modulus GPa |
Elongation (%) |
Density g/cm3 |
| 3820 | 588 | 0,7 | 1,93 |
Fiber Family
| Fiber Grade | M60JB 3K 50B | M60JB 6K 50B |
| Yield g/1000m | 103 | 206 |
| Sizing Content (% wt) | 1 | 1 |
| Fiber Type | Untwisted | |
| SurfaceTreatment (fiber / matrix adhesion) |
Standard | |
| Typical Matrix Compatibility Recommendation | Epoxy, Polyester, Vinylester, Phenolic, BMI | |
| Typical Process Recommendation | Weaving; Prepreg, Braiding; Filament Winding | |
| Supply Source | |
|
| Market | Space | |
